300W-500W Electric Rickshaw Parts Brushless Controller 24V 36V 48V

Patient Service, Five-Star Home,Needs Your Love And Support.

—— RIPON MD

Wish You a More Prosperous And Successful Future.

—— HAQUE MD ABDUL

ChangZhou Diesel, a Platform For Talent.

—— Sumit Agarwal

I'm Online Chat Now

300W-500W Electric Rickshaw Parts Brushless Controller 24V 36V 48V

China 300W-500W Electric Rickshaw Parts Brushless Controller 24V 36V 48V supplier

Large Image :  300W-500W Electric Rickshaw Parts Brushless Controller 24V 36V 48V

Product Details:

Place of Origin: JiangSu,China(Mainland)
Brand Name: SS GOLD;OEM
Certification: ISO9001:2008
Model Number: Standard

Payment & Shipping Terms:

Minimum Order Quantity: 100 Sets
Packaging Details: Carton And Foam
Delivery Time: 7-15 Working Days
Payment Terms: L/C, D/A, D/P, T/T, Western Union
Supply Ability: 100000 CTNS Per Month
Contact Now
Detailed Product Description
Driving Type: Electric Body Type: Open
Power: 300-500W Voltage: 24v
Name: Clamp Of Front Fork Material: Steel

300W-500W Electric Rickshaw Parts Brushless Controller 24V 36V 48V

250W 300w 350w e bike inteilligent Brushless bldc motor controller

Functions and features:



1. Use imitated torque control mode to achieve a smooth start-up of the power-assist vehicle, so that the power-assist driving will be smooth and natural;



2. The electric power-assist has fast response, and it is always consistent with the rider’s pedal action, which is to achieve the effect of torque boosting;



3. With a multi-protection functions such as the stall, over-current, over-temperature, under-voltage, speed driving, phase shortage, output short circuit etc., so as to protect the vehicle electronic control systems and traffic safety;



4. Hall or no hall motor drive, adapting to various kinds of high and low speed motor;



5. Controller power range is 500-1500W (18-25A);



6. It can be customized for all types of controllers for users.



250W 300w 350w e bike inteilligent Brushless bldc motor controller



Main technical parameters:



1. Rated voltage:DC24-72V;



2. Rated current:9-12A;



3. Maximum current:18-25A;



4. Rated power:250-750W;



5. Maximum power:500-1500W;



6. Static power consumption:<50mA;



7. Under-voltage protection:it can be set according to customer requirements;



8. Driving mode:square wave;



9. Waterproof:basic protection of water washout IP64;



10. Electromagnetic compatibility (EMC):outgoing lines can be added with the jacketed ring for interference protection;



11. Lights drive:Optional headlight control and instrument headlight indicator;



12. Housing holder:single-ended or both ends are with the ears;



13. Housing color:aluminum natural or black;



14. Product certification:CE certification;

300W-500W Electric Rickshaw Parts Brushless Controller 24V 36V 48V
